Square D by Schneide HOM3060M150PCVP 150A Breaker Plug-On Neutral Load Center Value Pack

150A Breaker Plug-On Neutral Load Center Value Pack

The Square D Homeline Value Pack 150 Amp 30-Space 60-Circuit Indoor Convertible Main Breaker Load Center for Plug-on Neutral breakers includes the cover and a selection of breakers. It is UL listed for residential and commercial power distribution. This load center is built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers. Homeline load centers are designed for the value-minded contractors, remodelers, builders and homeowners. Homeline load centers are engineered for fast installation and wire savings.

• 150A Breaker Plug-On Neutral Load Center Value Pack

• Dimension: 33.78 x 14.25 x 3.75 in.
• Cube: 1805.12
• Ampere Interruption Rating (AIR): 22k
• Bus Bar Material: Tin Plated Aluminum
• Cover Type: Combination
• Enclosure Material: Steel
• Feed Position: Top or Bottom
• Listing Agency Standards: UL Listed
• Maximum Number of Circuits: 60
• Number of Phases: 1
• Number of Spaces: 30
• Overall Depth: 35-7/8 inch
• Overall Height: 33-3/4 inch
• Overall Width: 14-1/4 inch
• Series: Homeline
• Voltage Rating: 120, 240
• Weight: 34.83 lbs
