The KVM HDMI over IP PoE Extender, UHD-4K allows HDMI & USB equipment to be connected up to 330ft (100m) over an Ethernet LAN, supports HDMI up to 4K @ 30Hz (444) and 4K @ 60Hz (420) via Cat5e/6 cable in multiple point-to-point and point-to-multipoint configurations. The Transmitter (500772-TX) and Receiver (500772-RX) support PoE (PD) if used with a PoE (PSE) Ethernet Switch. The Transmitter terminates to a computer server/workstation via an HDMI & USB port, The Receiver terminates to an HDMI display and up to 4 USB devices such as a keyboard, mouse, printer, drawing pad, storage device, camera, etc., via a 4 port USB hub. A single Receiver can be switched via hotkey sequences to any Transmitter on the network, allowing a single operator to manage numerous servers/workstations, in a distributed KVM application.
Features- Detects whether a device is a hub, switch, or PC
- Verifies the speed and duplex of a link, enabling you to spot network bottlenecks
- Includes a tone probe and tone generator for tracing cable and port locations
- Shows how cable pairs are wired and identifies straight-pinned and crossover configurations
- Determines the number of cable pairs required by a connected device
- Indicates the presence of Power over Ethernet and whether the power is endspan or midspan
- 1x Main unit
- 1x Remote probe unit
- 2x 9-V batteries
- 2x RJ-45-to-RJ-45 jumpers
- 1x Protective carrying pouch
- 1x User's manual
Specifications- Environment: HDMI 1.4
- Transmission: Transparent to the user
- Signals: HDMI 1.4 protocol, HDCP 1.4, HDCP 2.2
- Bandwidth (HDMI): 300MHz
- Network Requirement: 1000BaseT with PoE
- Bandwidth: Up to 500Mbps
- PoE Standard: IEEE 802.3af
- Weight: 1.5 lbs
