Capable of driving four displays from one signal, the Matrox Q2GH4K QuadHead2Go Q155 multi-monitor controller appliance provides complete video wall scalability and flexibility. This system-independent appliance is designed to power any video wall configuration of any possible dimension, from any HDMI video source - reliably delivering flawless image quality across expansive, artistic video wall displays, suited for digital signage in a wide range of industries. QuadHead2Go's on-device buttons and pre-set configurations ensure an out-of-the-box, trouble-free installation experience.
The included Matrox PowerWall software offers an intuitive and feature-rich interface to configure the latest emerging, artistic, and innovative video walls, making installations as easy as 1-2-3.
Features- Complete flexibility
- Drive up to four pristine quality Full HD displays from a single video signal
- Expand to a video wall configuration of any size by using multiple QuadHead2Go units
- Create a video wall from any content source, including professional graphics cards and integrated GPUs
- Design modern and artistic video wall layouts with free rein
- Fashion countless forms of setups - arrange displays in 4x1, 1x4, 2x2, 3x1, 1x3, 2x1
- Design any custom configuratiorray with the intuitive Matrox PowerWall software
- Ensure compatibility with professional-grade graphics cards and media players with HDMI support
- Eliminate physical handling by controlling and updating the units remotely from anywhere on the network (LAN)
- Select and set the display layout by cycling through pre-set configurations
- Set up display positions, fine tune bezels, and also troubleshoot with ease, by accessing the built-in
Specifications- Product type: 1 input and 4 outputs
- Form factor: Appliance (p/n: Q2G-H4K)
- Input connector (video & audio support): 1 x HDMI
- Max input resolutions: 3840x2160 @60Hz, 3840x2160 @30Hz, 7680x1080 @60Hz, 7680x1080 @30Hz, 1920x4320 @60Hz, 1920x4320 @30Hz
- Output connector (video & audio support): 4 x HDMI
- Max output resolutions: 1920x1080 @60Hz, 1920x1080 @30Hz, 1920x1200 @60Hz, 1920x1200 @30Hz
- Memory: 1 GB
- Non-rectangular/artistic video walls support: Yes
- Rotation: Yes
- Multi-unit support: Yes
- Bezel management: Yes
- Clone mode: Yes
- HDCP support: Yes
- Video scaling: Matrox's advanced multi-channel Video Scaling Engine
- Video cropping: Yes
- Audio format: AAC, PCM, Stereo, and Mono
- Audio sampling rate: 44.1 KHz and 48 KHz 16-bit stereo
- Standard: Ethernet 10/100/1000 Base-T, Auto-Detect, Half/Full-Duplex
- Connector: RJ45, IP version, IPv4/IPv6
- IP addressing: DHCP (default) and Static IP
- Control interface: 1 x 10/100/1000 Base-T RJ45 Ethernet port
- Command & control protocols: HTTP/HTTPS, UPnP (discovery), mDNS and DNS-SD (discovery)
- Firmware update: Via network interface
- Input color space: 8:8:8 (24 bits per pixel). YUV: 4:4:4, 4:2:2 (8 bits per component)
- Output color space: 8:8:8 (24 bits per pixel)
- Storage conditions Temperature: -40 to 70 degC/-40 to 158 degF
- Storage conditions Humidity: 5% to 95% (non-condensing)
- Power supply: 100-240 VAC in, 12 VDC out, 42 W DIN4 locking power connector
- Maximum power consumption: 15 W
- Dimensions (WxHxD): 5.50 x 1.25 x 7.13 in (13.97 x 3.18 x 18.11 cm)
- Hardware included: 4 x 6 feet power cables for US, EU, UK, Aus/Nz, 1x 12 V, 3.5 A, 42 W external power supply with DIN 4 connector
- Regulatory compliance: EMC Class A: FCC, CE, KC, RCM
- Weight: 1.5 lbs
