Lightronics LGT-DB612 Distributed Dimming Bar - Black

Our engineers envisioned the ultimate dimmer bar, a product that offers substantial Savings, Versatility and Reliability. Utilizing Lightronics DB series Distributed Dimming System, you can save up to 40% on materials and labor during the installation of your new lighting control system. The DB Series is ideally suited for ALL stage applications including theaters, schools and churches. It’s designed to operate a minimum of 15+ years with a single removable electronics module that contains all of the electronics for easy swap out.

• 6 Channels
• 1200W per Channel
• DMX-512
• Mounting Track
• Fast Acting Magnetic Circuit Breakers
• Terminal Strip Input
• Edison Outputs
• UL-508 Compliant

• Color: Black
• Channels / Capacity: 6 at 1200W Each
• Semiconductors: 40A, 400V Triacs, 300% overhead
• Power Requirements: 120/240VAC Single Phase, 30 Amps 120/208VAC Three Phase, 20 Amps
• Control Protocol: USITT DMX-512
• Weight: 26 lbs
