Lightronics LGT-IDP104 IDP104 DMX Opto-Isolation & Distribution Console
MSRP:
$489.76
$332.32
The IDP104 is an optically isolated DMX splitter with one DMX input and four independent DMX output circuits.
Features- Accepts 1 DMX Signal
- Retransmits into 4 Separate DMX Drive Signals
- Optical Isolation
- Protected Outputs
- Provided with UL Listed Power Supply
Specifications- Power Input: 13VAC, 600ma
- Output Signal: 4 DMX-512 Control Chains via 5 Pin XLRs
- Input Signal: DMX-512
- Size: 5" x 2.5" x 5.5" (portable), 12" x 10" x 4" (wall mount)
- Weight: 2 lbs
