Livestream Studio HD51-4K is an all-in-one live production switcher from the makers of the world's leading live video platform. With five HD-SDI or HDMI inputs, all the Studio Software features, and a high performance system, Studio HD51-4K is the perfect combination of powerful, simple and affordable. Simply plug in a screen and go.
Features- 5x HDMI or SDI inputs
- 1x SDI / HDMI output
- Up to 2 screens
- 10x Remote camera tracks
- 2x Media tracks
- 3 GFX tracks
- 20 hours of broadcast quality recording
- Analog audio in
- Optional included rack-mount ears
- Front-panel USB / headphone
Specifications- Hd-Sdi Inputs: 5
- Embedded Audio Input: 5 Stereo Or 40 Mono Hd-Sdi Embedded Audio Inputs
- Audio Monitoring (1/8"): 1
- HDMI Inputs: 5
- HDMI Outputs: 1
- Standard/High Definition SDI Output: 1
- Analog Audio (1/8") Input: 1
- Analog Audio (1/8") Output: 1
- Media Sources: 7 integrated digital media sources for video & graphics playback. 2 DDRs (video clip playback with built-in transcoder), 3 GFX (graphics), 2 Color Bars / Background Color
- Remote Camera: 10 x Remote camera module for ingesting video/audio over local WiFi or Ethernet network, downlinking streams, and Interviews via WebRTC.
- Format Converter: Built-in broadcast quality format converter for every input with automatic format detection. Allows use of any camera and video source without matching video formats
- Built-In Multiview: On-screen full field rate multiview of all live inputs, Preview, Program Out, GFX and DDR, Audio PPM overlay with peak hold feature on all inputs and outputs. Resizable layout allowing hiding of all controls to maximize multiview screens.
- External Multiscreen: 1x Extended Screen output using HDMI
- Video Switcher/Mixer: Mixer & Effects Bank (M/E) with no upstream keyer. transitions: SMPTE Wipe, Cut & Fade (Auto transition with adjustable duration in frames, manual via on-screen T-BAR or keyboard shortcuts)
- Graphics Downstream Key: 3 x Graphics DSK (downstream key) channels. One channel for GFX1, one channel for GFX2 and onechannel for GFX 3. Independent or locked transition controls (fade/cut/wipe). Preview on multiview
- Graphics & Titling: Load JPG or PNG files (full transparency support with PNG files). Add text (set position/font/size/color) over any loaded image file within the GFX1, GFX2 or GFX3
